SSL (7W-24W)
Solar street lights are beneficial for all, providing a cost-effective and eco-friendly way to illuminate streets. They are easy to install and offer bright lighting without adding to electricity expenses.
Our USP:
Battery provided in the set is lithium-ion.
Solar Module cell have high efficiency Multi Crystalline silicon cells / Mono Crystalline silicon cells.
GI Galvanised Octagonal Pole (5mtr+1mtr)
IP 65 classified
PRONTO RENEWABLES ENERGY PVT LTD | ||||||
PRONTO SOLAR STREET LIGHT - SPECIFICATIONS | ||||||
S.No. | Street Light | 7W | 9W | 12W | 18W | 24W |
1 | Solar Module Rating (Wp) | 40 | 40 | 75 | 100 | 120 |
2 | Solar Module Cell Type | High efficiency Multi Crystalline silicon cells / Mono Crystalline silicon cells | ||||
3 | Battery Voltage (LiFePo4) | 12V | 12V | 12V | 12V | 12V |
4 | BATTERY Capacity | 40Ah | 40Ah | 75Ah | 100Ah | 120Ah |
5 | Charging Efficiency | <96% | ||||
6 | LED Light Operating Voltage | (11-16)V | ||||
7 | Charge Controller type | PWM | PWM | PWM | PWM | PWM |
8 | Driver Efficiency | 90.00% | 91.60% | 90.80% | 90.20% | 90.20% |
9 | Lumen Efficiency/Watt | >120 Lumen/W | ||||
10 | Pole | GI Galvanised Octagonal Pole (5mtr+1mtr) | ||||
A | INDICATIONS | |||||
1 | Charging | Green LED Glow | ||||
2 | Battery LOW | RED LED Glow | ||||
B | PROTECTIONS | |||||
1 | Overcharge | Provided | ||||
2 | Deep Discharge / Battery Reverse | Provided | ||||
3 | Load Open & Short | Provided | ||||
4 | Reverse Current Flow | Provided | ||||
5 | Open and Short Circuit | Provided | ||||
MISCELLANEOUS | ||||||
1 | IP Class | IP65 | ||||
2 | Humidity | 95% | ||||
3 | Power Factor | 1 | ||||
4 | Warrenty | 5years | ||||
NOTE:- DUE TO CONTINUE IMPROVEMENT IN PRODUCT , DESIGN MAY BE CHANGE. |
